"揭秘喷淋式蒸发器：检重机的奇妙工作原理"

它利用喷淋装置将液态的冷媒喷洒在换热管表面并蒸发，极大的提高了蒸发器的换热效率；同时，它避免了满液式蒸发器需大量充注冷媒的缺点，降低空调的使用成本，更利于压缩机的回油。节流降压后的液态冷媒，通过冷媒进口进入冷媒分布器，冷媒分布器将液态冷媒均匀地喷洒在换热管束上。liquid state refrigerant, due to the force of gravity, flows downward and forms a thin layer on the outer surface of the heat exchanger tube. This thin layer absorbs heat from the cold refrigerant inside the heat exchanger tube and evaporates into a gas. The cold refrigerant, having lost its heat, is cooled.

The advantages of this design are as follows:

Cold media evaporation occurs on the outside of the heat exchanger tubes, resulting in smaller temperature differences and higher convective coefficients.

The amount of cooling agent required is reduced, which can save costs and be more environmentally friendly.

After evaporation, the cooling agent returns to the compressor; meanwhile, it continuously flows downward and accumulates at the bottom of the evaporator for easier return oil.

Selection Parameters:

Cooling capacity range: 282KW~2040KW

Evaporating temperature: 5℃

Special specifications and sizes can be customized according to customer requirements

Single-stage spray-type evaporator,

Double-stage spray-type evaporator
